Victron Blue Solar MPPT 100/15 Charge Controller

The Victron Blue Solar MPPT 100/15 Charge Controller is designed to optimize the charging process for solar energy systems, ensuring maximum energy harvest and battery longevity. With advanced MPPT technology, it significantly improves energy efficiency, especially in variable weather conditions.

Features

• Ultra-Fast Maximum Power Point Tracking (MPPT): Increases energy harvest by up to 30% compared to PWM controllers, especially in cloudy conditions.
• Automatic Battery Voltage Selection: Automatically detects and adjusts to 12V or 24V battery systems.
• Battery Life Algorithm: Extends battery life by intelligently managing load disconnect levels based on the state of charge.
• Real-Time Monitoring: Compatible with VE.Direct Bluetooth Smart dongle for remote monitoring and control via smartphone.
• Programmable Charge Algorithm: Offers flexibility in charging profiles to suit different battery types and requirements.
• Load Output Function: Prevents over-discharge by disconnecting loads when battery voltage drops below a preset level.
• High Efficiency: Peak efficiency of 98% ensures minimal energy loss during the charging process.

Specifications

• Battery Voltage: 12/24V Auto Select
• Rated Charge Current: 15A
• Max. PV Open Circuit Voltage: 100V
• Max. PV Short Circuit Current: 15A
• Nominal PV Power (12V): 220W
• Nominal PV Power (24V): 440W
• Self-Consumption (Load On): 25 mA (12V), 15 mA (24V)
• Operating Temperature: -30 to +60 °C
• Protection Category: IP43 (electronic components), IP22 (connection area)
• Weight: 0.65 kg
• Dimensions (H x W x D): 100 x 131 x 60 mm
