UNV H.265 Hybrid NVR - 16 Channel Analog XVR

The UNV H.265 Hybrid NVR is a state-of-the-art 16-channel network video recorder designed for high-definition surveillance solutions. Supporting various video formats and camera types, it ensures versatile and efficient monitoring for both residential and commercial applications.

Features

• H.265/H.264 Support: Efficient video compression formats that reduce bandwidth and storage requirements while maintaining high quality.
• Audio Over Coaxial: Supports audio transmission over coaxial cable for TVI cameras, enhancing surveillance capabilities.
• Multi-Camera Compatibility: Compatible with TVI, AHD, CVI, CVBS, and IP cameras, allowing for flexible system integration.
• 16-Channel BNC Input: Offers extensive input options for connecting multiple cameras simultaneously.
• High-Resolution Output: Features 1-ch HDMI and 1-ch VGA output supporting resolutions up to 1920x1080 for clear video playback.
• Long Transmission Distance: Capable of long-distance transmission over coaxial cable, ensuring reliable connectivity.
• ONVIF and RTSP Protocol Support: Seamlessly integrates with mainstream cameras that support ONVIF and RTSP protocols.
• User-Friendly Interface: Designed for easy setup and operation, making it suitable for users of all technical levels.

Specifications

• Model: XVR301-16G3
• Video Input: 16-channel BNC input; 8-channel IP input (expandable to 16 after analog camera conversion)
• Audio Input: 1-ch RCA, G.711U compression
• HDMI Output: 1920x1080 at 60Hz
• VGA Output: 1920x1080 at 60Hz
• Recording Resolution: Up to 5MP Lite
• Incoming Bandwidth: 40Mbps (up to 56Mbps after all analog camera conversion)
• Outgoing Bandwidth: 64Mbps
• Remote Users: Supports up to 128 remote users
• Power Supply: 12V DC, Power Consumption: ≤ 10W (without HDD)
• Operating Temperature: -10°C to +55°C, Humidity ≤ 90% RH (non-condensing)
• Dimensions: 260mm x 226mm x 47mm
• Weight: ≤ 1.1 Kg
