Ubiquiti UniFi Pro Max Switch 48 with 32PoE 16x 2.5Gbps PoE++ 720W | USW-Pro-Max-48-PoE

The Ubiquiti UniFi Pro Max Switch 48 PoE (USW-Pro-Max-48-PoE) is a state-of-the-art 48-port Layer 3 managed network switch designed for enterprise networking. It features 16 high-speed 2.5 GbE ports and 32 Gigabit Ethernet ports, all equipped with Power over Ethernet (PoE) support, making it perfect for powering devices such as advanced IP cameras, access points, and VoIP phones. With Etherlighting™ technology, it provides visual indicators for port status, simplifying network management and troubleshooting. The switch boasts a substantial PoE power budget of 720W, efficiently supporting a wide range of PoE devices. Additionally, it includes four 10G SFP+ ports for high-speed uplinks, ensuring seamless data transfer across the network. Managed through the UniFi Network platform, the Pro Max 48 PoE offers advanced Layer 3 features, including DHCP server capabilities, inter-VLAN routing, and static routing, catering to complex networking requirements.

Features

• 48 Ethernet ports:
• 16 x 2.5 GbE RJ45 ports (8 PoE++ 60W, 8 PoE+ 30W)
• 32 x 1 GbE RJ45 ports (8 PoE++ 60W, 24 PoE+ 30W)
• 4 x 10G SFP+ ports for high-speed uplinks
• Total PoE availability of 720W
• Etherlighting™ technology for intuitive port status indication
• 1.3" touchscreen display for real-time system monitoring
• Layer 3 features:
• - DHCP server and relay
• - Inter-VLAN routing
• - Static routing
• Managed via UniFi Network platform
• Rack-mountable 1U form factor
• Redundant power support with DC backup input
• Advanced security features including 802.1X control, MAC-based ACLs, and DHCP snooping
• Quality of Service (QoS) support for traffic prioritization
• Pro AV profiles for seamless integration with AV systems
• Loop protection and port isolation to enhance network stability
• Support for jumbo frames and LLDP-MED
• Voice VLAN support for optimized VoIP performance
• NDAA compliant

Specifications

• Switching Capacity: 224 Gbps
• Total Non-Blocking Throughput: 112 Gbps
• Forwarding Rate: 167 Mpps
• Supported VLANs: 1,000
• MAC Address Table Size: 32,000 entries
• ARP Entries: 12,000
• IPv4 Routes: 12,000
• IPv4 Static Routes: 256
• Packet Buffer Size: 2 MB
• Access Lists:
• - IPv4: 128
• - MAC: 128
• Max. PoE Wattage per Port:
• - PoE: 15.4W
• - PoE+: 32W
• - PoE++: 64W
• Max. Power Consumption: 100W (excluding PoE output), 820W (including PoE output)
• Power Supply: Internal AC/DC, 870W
• Supported Voltage Range: 100–240V AC
• Heat Dissipation: 341.2 BTU/hr (excluding PoE output)
• Enclosure Material: SGCC steel
• Mount Material: SGCC steel
• Supported Rack Depth: 400–1200 mm (15.7–47.2")
• LCM Display: 1.3" touchscreen
• ESD Protection: Air: ±16kV, Contact: ±12kV
• Ambient Operating Temperature: -5 to 40°C (23 to 104°F)
• Ambient Operating Humidity: 10 to 90% non-condensing
• Certifications: CE, FCC, IC, Anatel: 06373-24-08356
