Ubiquiti UISP airMAX NanoStation 5AC 5GHz 16dBi Radio | NS-5AC

The Ubiquiti UISP airMAX NanoStation 5AC (NS-5AC) is a high-performance Wi-Fi radio designed for point-to-point (PtP) and customer premises equipment (CPE) applications. It offers a link range of approximately 15+ km, making it suitable for establishing long-distance wireless connections. The device features a dedicated management Wi-Fi radio for easy setup via the UISP mobile app and operates within the 5 GHz frequency band, providing enhanced throughput and reduced interference.

Features

• Dedicated management Wi-Fi radio for streamlined setup using the UISP mobile app.
• Operates in the 5 GHz frequency band, offering improved throughput and reduced interference.
• Supports channel bandwidths of 10/20/30/40/50/60/80 MHz.
• Dual Gigabit Ethernet ports for flexible connectivity options.
• UV-resistant plastic enclosure for enhanced durability in various environmental conditions.
• Includes pole and wall mounting kits for versatile installation.
• Compliant with CE, FCC, and IC certifications.

Specifications

• Networking Interface: (2) Gigabit Ethernet RJ45 ports
• Power Method: PoE alternative A (pairs 1, 2+; 3, 6 Return); Passive PoE 2-pair (4, 5+; 7, 8 return)
• Power Supply: 24V, 0.5A Gigabit PoE adapter (included)
• Supported Voltage Range: 44–54V DC; 22–27V DC
• Max. Power Consumption: 9W
• ESD/EMP Protection: Air/contact: ±24 kV
• LED Indicators: Power, Ethernet, (4) signal strength
• Ambient Operating Temperature: -40 to 70° C (-40 to 158° F)
• Ambient Operating Humidity: 5 to 95% noncondensing
• Gain: 16 dBi
• Cross-Polarization Isolation: 20 dB min.
• Max. VSWR: 1.6:1
• Beamwidth: 45° (H-pol) / 45° (V-pol) / 45° (Elevation)
• Polarization: Dual linear
• Operating Frequency (MHz): Worldwide: 5150-5875 MHz; USA: U-NII-1: 5150-5250 MHz, U-NII-2A: 5250-5350 MHz, U-NII-2C: 5240-5725 MHz, U-NII-3: 5725-5850 MHz
• Management Radio (MHz): Worldwide: 2412 - 2472 MHz; US/CA: 2412 - 2462 MHz
• NDAA Compliant: Yes
