Ubiquiti UISP airMAX NanoBeam M5 5GHz 16dBi Radio | NBE-M5-16

The Ubiquiti UISP airMAX NanoBeam M5 5GHz 16dBi Radio (NBE-M5-16) is a high-performance wireless bridge designed for point-to-point (PtP) and point-to-multipoint (PtMP) applications. Operating in the 5 GHz band, it delivers a 16 dBi gain, ensuring robust and reliable connectivity over long distances. Its compact, all-in-one design integrates the radio and antenna into a single unit, simplifying installation and reducing the device's footprint. The NanoBeam M5 is particularly effective in environments with high RF noise, as its focused beamwidth enhances noise immunity by filtering out unwanted signals.

Features

• Integrated radio and antenna for a compact design
• Operates in the 5 GHz frequency band
• 16 dBi antenna gain
• Supports both PtP and PtMP configurations
• Enhanced noise immunity with a focused beamwidth
• Passive PoE support for flexible power options
• Durable, UV-stabilized plastic enclosure suitable for outdoor use
• Easy installation with pole-mount and wall-mount options
• Wind survivability up to 200 km/h (125 mph)
• Operates in temperatures ranging from -40 to 70°C (-40 to 158°F)

Specifications

• Processor: Atheros MIPS 74Kc, 560 MHz
• Memory: 64 MB DDR2 RAM, 8 MB Flash
• Networking Interface: (1) 10/100 Mbps Ethernet Port
• Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
• Power Supply: 24V, 0.5A PoE Adapter (Included)
• Max. Power Consumption: 6W
• ESD/EMP Protection: Air/contact: ±24 kV
• LED Indicators: Power, LAN, WLAN (4 LEDs for signal strength)
• Operating Frequency: Worldwide: 5150 - 5875 MHz
• Channel Sizes: 5/8/10/20/30/40 MHz
• Max. VSWR: 1.5:1
• Polarization: Dual linear
• Certifications: FCC, IC, CE, RoHS
• NDAA Compliance: Yes
