Ubiquiti UISP 60GHz/5GHz Wave Nano | Wave-Nano-EU

The Ubiquiti UISP 60GHz/5GHz Wave Nano is a powerful PtMP radio solution designed for high-performance connectivity. Featuring advanced Wave technology, it offers exceptional throughput and range, making it ideal for last-mile deployments in challenging environments.

Features

• High-Gain Antenna: Integrated high-gain antenna for superior signal strength.
• Dual-Band Operation: 60GHz for high-speed connectivity and 5GHz backup for redundancy.
• Long Range Capability: Supports PtP links up to 12 km with a maximum link range of 5 km when connected to a Wave AP.
• True Duplex Performance: Delivers up to 2 Gbps total throughput (1 Gbps duplex) for efficient data transmission.
• Integrated GPS: Built-in GPS antenna for precise location tracking and network planning.
• Bluetooth Setup: Simplifies installation and configuration via the UISP® Mobile app.

Specifications

• Antenna Gain: 60GHz: 41dBi; 5.8GHz: 19dBi
• Beamwidth: 60GHz: 1°; 5GHz: 17°
• Data Rate: 60GHz: Up to 2Gbps; 5.8GHz: 800Mbps
• Ethernet Ports: 1x 10/100/1000
• Max Power Consumption: 18W
• Operating Temperature: -40°C to 60°C
• PoE Input: 24V or 48V Passive PoE
• Dimensions: Ø256.5 x 113.5 mm
• Weight: 1.2 kg
