Ubiquiti UISP 60GHz/5GHz Wave Long Range Radio | Wave-LR

The Ubiquiti UISP Wave Long-Range (Wave-LR) is a 60 GHz Point-to-MultiPoint (PtMP) station designed to deliver high-speed wireless connectivity over extended distances. Capable of achieving up to 2 Gbps total throughput (1 Gbps duplex), it is ideal for Internet Service Providers (ISPs) and enterprises requiring robust, long-range wireless solutions. The device features a 5 GHz Wi-Fi 6 (802.11ax) backup radio, ensuring uninterrupted connectivity even in challenging conditions. Integrated GPS and Bluetooth facilitate precise alignment and simplified setup via the UISP Mobile app. Its durable, weatherproof design allows for reliable outdoor deployment in various environmental conditions.

Features

• 60 GHz primary radio with up to 2 Gbps total throughput (1 Gbps duplex)
• 5 GHz Wi-Fi 6 (802.11ax) backup radio supporting up to 800 Mbps throughput
• Maximum link range of up to 8 km (5 miles)
• Integrated GPS for precise device coordination
• Bluetooth for easy setup via the UISP Mobile app
• Supports both bridge and router modes
• Single Gigabit Ethernet RJ45 port with passive PoE support
• Weatherproof design with IPX6 rating
• Operates in temperatures ranging from -40°C to 60°C (-40°F to 140°F)
• Managed through the UISP application (version 1.4.5 and later)

Specifications

• Processor: Dual-core ARM® Cortex®-A53 at 1 GHz
• Memory: 512 MB DDR3L
• Networking Interface: (1) Gigabit Ethernet RJ45 port
• Maximum Power Consumption: 20W
• Power Method: Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) or Passive PoE 2-pairs (4, 5+; 7, 8-) for 44–54V DC only
• Supported Voltage Range: 44–54V DC; 22–27V DC
• Power Supply: 48V DC, 0.65A gigabit PoE adapter (included)
• Operating Temperature: -40°C to 60°C (-40°F to 140°F)
• Operating Humidity: 5% to 95% non-condensing
• Certifications: FCC, IC, CE
