Ubiquiti UISP 60GHz/5GHz PtMP Wave Station | Wave-Pico

The Ubiquiti UISP 60GHz/5GHz PtMP Wave Station is a high-performance wireless communication device designed for dense urban environments. It features a 60GHz PtMP (Point-to-Multipoint) operation with a 5GHz failover capability, ensuring reliable connectivity even in challenging conditions. This versatile device can also be configured for PtP (Point-to-Point) operation, making it suitable for various network setups.

Features

• 60GHz PtMP Operation: Provides high-speed wireless communication suitable for dense urban deployments.
• 5GHz Failover: Ensures reliability by automatically switching to a backup frequency in case of interference.
• Flexible Configuration: Can be set up for both PtMP and PtP operations to accommodate different networking needs.
• High Data Rates: Supports data rates of up to 2Gbps on the 60GHz band and 800Mbps on the 5GHz band.
• Integrated Antenna: Equipped with a high-gain antenna for enhanced signal performance.

Specifications

• Antenna Gain: 60GHz: 27.7dBi ; 5.8GHz: 9dBi
• Beamwidth: 60GHz: 6° ; 5GHz: 50°
• Max Data Rate: 60GHz: Up to 2Gbps ; 5.8GHz: 800Mbps
• Ethernet Ports: 1x 10/100/1000
• Max Power Consumption: 10W
• Operating Temperature: -40°C to 60°C
• PoE Input: 24V or 48V Passive PoE
• Dimensions: Ø152.1 x 55.8 mm
• Weight: Without mount: 347 g (12.2 oz), With mount: 409 g (14.4 oz)
