Ubiquiti Gigabit PoE Adapter 24V 7W with No Cable | POE-24-7W-G-WH

The Ubiquiti POE-24-7W-G-WH is a 24V, 7W Gigabit Power over Ethernet (PoE) adapter designed to deliver reliable power and data connectivity to compatible devices. This adapter is particularly suitable for Ubiquiti's range of wireless access points, IP cameras, and other PoE-enabled equipment. By combining power and data transmission over a single Ethernet cable, this adapter simplifies installations and reduces cable clutter. Its built-in surge protection and clamping protection features help safeguard connected devices against electrical surges and electrostatic discharge (ESD), enhancing the longevity and stability of your network infrastructure.

Features

• Delivers 24V DC at 0.3A output, providing up to 7.2W of power.
• Equipped with a Gigabit LAN port for high-speed data transmission.
• Includes remote reset capability and a physical reset button for easy device management.
• Offers surge protection, clamping protection, and maximum surge discharge to protect connected devices.
• Supports 2-pair powering on pins 4, 5 (+) and pins 7, 8 (-).
• Features an IEC-320 C6 AC connector and RJ45 shielded sockets for data input and PoE output.
• Certified by CE, FCC, IC, and UL for compliance with safety standards.

Specifications

• Output Voltage: 24V DC at 0.3A
• Input Voltage: 100-240V AC at 50/60Hz
• Input Current: 0.3A at 120V AC; 0.2A at 240V AC
• Inrush Current: <40A peak at 120V AC; <70A peak at 230V AC
• Efficiency: 80% or higher
• Output Ripple: 1% maximum
• Switching Frequency: 65 kHz
• Line Regulation: ≤ 3%
• Load Regulation: ≤ 5%
• Operating Temperature: 0 to 40°C (32 to 104°F)
• Storage Temperature: -30 to 70°C (-22 to 158°F)
• Operating Humidity: 35 to 95% non-condensing
• Surge Protection: Difference and common mode
• Clamping Protection: 11V data, 60V power
• Max. Surge Discharge: 1500A (8/20 μs) power
• Peak Pulse Current: 36A (10/1000 μs) data
• Shunt Capacitance: <5 pF data
• Response Time: <1 ns
