Ubiquiti 10G Multi-WAN UniFi Cloud Gateway Fiber without M.2 SSD Tray | UCG-Fiber

The Ubiquiti UniFi Cloud Gateway Fiber (UCG-Fiber) is a high-performance desktop 10G cloud gateway designed to meet the demands of modern fiber-to-the-premises (FTTP) networks and comprehensive UniFi system deployments. It integrates dual 10G WAN ports (one SFP+ and one RJ-45), a 4-port 2.5 GbE switch (including one PoE+ port), and supports selectable NVMe SSD storage up to 2 TB. This compact device offers enterprise-grade routing, security, and SD-WAN capabilities, making it ideal for businesses requiring robust and scalable networking solutions.

Features

• Dual 10G WAN ports: (1) 10 GbE RJ-45 and (1) 10 G SFP+
• LAN connectivity: (1) 10G SFP+ port and (4) 2.5 GbE RJ-45 ports, with one PoE+ enabled
• Selectable NVMe SSD slot supporting up to 2 TB (SSD sold separately)
• 5 Gbps IDS/IPS throughput for robust security in high-traffic environments
• Manages over 50 UniFi devices and supports 500+ clients simultaneously
• Compact desktop form factor weighing approximately 675 g without SSD
• PoE budget of 30 W
• Full UniFi application suite support, including Network, Protect, Access, Talk, and Connect
• Advanced firewall, VPN, and SD-WAN features
• 0.96" LCM status display and Bluetooth management
• NDAA compliant with CE, FCC, and IC certifications

Specifications

• Processor: Quad-core ARM Cortex-A73 at 2.2 GHz
• Memory: 3 GB DDR4
• Storage: 1 × NVMe M.2 2280 slot (up to 2 TB SSD, optional)
• WAN Ports: 1 × 10G RJ-45 and 1 × 10G SFP+
• LAN Ports: 1 × 10G SFP+ and 4 × 2.5 GbE RJ-45 (one PoE+)
• PoE Budget: 30 W (max)
• IDS/IPS Throughput: 5 Gbps
• Power Consumption: 29.4 W (excluding PoE output)
• Operating Temperature: 0 – 40 °C
• Certifications: CE, FCC, IC – NDAA compliant
