Teltonika Industrial 5-Port Gigabit Switch - Unmanaged, Auto MDI/MDIX

The Teltonika Industrial 5-Port Gigabit Switch is an unmanaged Ethernet switch designed for industrial applications, featuring five Ethernet ports with support for auto MDI/MDIX crossover. This compact and robust switch ensures reliable connectivity in demanding environments, making it ideal for IoT and automation solutions.

Features

• Unmanaged Switch: Simple plug-and-play operation without the need for configuration.
• Auto MDI/MDIX Support: Automatically detects the type of cable used, eliminating the need for crossover cables.
• DIN Rail or Wall Mountable: Flexible installation options for various environments.
• Passive PoE Input: Powers the switch through the Ethernet ports, compatible with a voltage range of 9-30 VDC.
• Industrial Grade Design: Built to withstand harsh conditions with an operating temperature range of -40 °C to 75 °C.

Specifications

• Ethernet Ports: 5 x RJ45, 10/100 Mbps
• Bandwidth: Non-blocking 1 Gbps
• MAC Address Table Size: 2K entries
• Jumbo Frame Support: Up to 2048 bytes
• Power Consumption: Idle 0.3 W / Max 0.9 W
• Casing Material: Aluminium housing
• Ingress Protection Rating: IP30
• Regulatory Compliance: CE, UKCA, FCC, RoHS, WEEE
• Dimensions: 113.1 mm (W) x 27.4 mm (H) x 80.5 mm (D)
• Weight: 146.5 g
