Radial USB Pro Laptop DI with 24.96 Headphone Output

Achieve seamless integration of your digital audio sources with professional audio systems using the Radial USB-Pro Stereo USB DI Box. This high-performance device converts USB audio signals to balanced XLR outputs, ensuring superior sound quality and reliable performance. The USB-Pro is perfect for interfacing computers with PA systems, recording interfaces, and more, making it an essential tool for live sound engineers and recording professionals.

Features

• High-Quality Audio Conversion: Custom decoder with analog line drive for exceptional sound quality.
• Wide Frequency Response: 5Hz to 40kHz (30Hz to 18kHz with isolation) for accurate audio reproduction.
• Dynamic Range: Greater than 90dB ensures clear, detailed sound.
• Low Distortion: Total harmonic distortion of just 0.01%.
• Versatile Connectivity: Features mono sum, ground lift, level control, and headphone output for flexibility in various applications.
• USB Compatibility: Compatible with Windows XP/Vista/Win7/Win8/Win10 and Mac OS, supporting WDM, MME, CoreAudio, DirectSound, WASAPI, and .WAV sound files.
• Robust Construction: 14-gauge steel chassis for durability and reliability.
• Bus Powered: Operates on USB bus power, eliminating the need for external power supplies.

Specifications

• Audio Circuit Type: Custom decoder with analog line drive
• Frequency Response: 5Hz ~ 40kHz (30Hz ~ 18kHz with isolation)
• Dynamic Range: >90dB
• Gain: +8dBu
• Total Harmonic Distortion: 0.01%
• Output Impedance: 250Ω nominal
• Noise Floor: -90dB
• Maximum Output: +8dBu
• Compatibility: Software: Windows XP/Vista/Win7/Win8/Win10 and Mac OS; Sound file: WDM, MME, CoreAudio, DirectSound, WASAPI, .WAV
• Sampling Rate: 44.1kHz / 48kHz / 96kHz auto sensing
• Stereo Separation: 75dBu
• Input Connectors: USB connector B-type
• Output Connectors: 2 x XLR-M, 3.5mm headphone output
• Construction: 14-gauge steel
• Size: 127mm x 84mm x 48mm (5.0" x 3.3" x 2")
• Weight: 0.68kg (1.5lb)
• Power: USB bus powered 500mA maximum
• Operating Conditions: For use in dry locations only between 5°C and 40°C
• Warranty: Radial 3-year, transferable
• Part Number: R800 1050 00
