Optimal Audio Up 4O - 4" Passive Ceiling Speaker, 10W, 100

The Optimal Audio Up 4O is a discreet 4-inch passive ceiling speaker designed to deliver consistent audio coverage and high-quality sound in various commercial settings. With its open-backed design, it is ideal for environments where aesthetics and affordability are key considerations, such as hotels, retail stores, restaurants, and more.

Features

• Full-Range Sound: Equipped with a 4-inch (105mm) driver, the Up 4O provides clear and balanced audio suitable for both music and speech.
• Wide Coverage Pattern: The speaker features a 130° conical dispersion pattern, ensuring sound is evenly distributed across small to medium-sized spaces.
• 70/100V Line Operation: Designed to operate on 70V or 100V line systems, it includes transformer taps for flexible power options.
• Easy Installation: Comes with an integral fixing system for simple and clean mounting in ceilings with minimum cavity depth.
• Discreet Design: The unobtrusive white finish and open-backed design allow for seamless integration into various architectural environments.
• Durable Construction: Features a perforated steel grille for protection and a robust ABS baffle for longevity.

Specifications

• Type: Full range, passive, ceiling speaker
• Frequency Response: 87Hz – 15kHz ± 3dB -10dB @ 60Hz
• Drivers: 4" (105mm), coated paper
• Rated Power (AES): 10W
• Nominal Impedance: Tap Dependent
• Sensitivity (1W/1m): 93dB
• Maximum SPL: 100dB (cont)
• Recommended High-Pass Filter: 24dB/Octave @ 80Hz
• Transformer Taps @ 70V: 6, 3, 1.5, 0.75W
• Transformer Taps @ 100V: 6, 3, 1.5W
• Dispersion: 130˚ conical
• Dimensions (inc. Grille): Ø 202mm x D 117mm (Ø 7.95" x D 4.62")
• Cut-Out Diameter: 178mm (7.01")
• Weight: 1.3kg (2.9lbs)
