Mimosa C5X - 4.9-6.4GHz PTP/PTMP Modular Radio

The Mimosa C5X is an ultra-rugged, versatile radio solution designed for Point-to-Point (PTP) and Point-to-Multipoint (PTMP) applications. With extended frequency operation from 4.9 to 6.4 GHz and best-in-class noise immunity, it provides exceptional flexibility and cost efficiency for high-speed wireless connectivity.

Features

• Modular Antenna Options: The C5X supports four twist-on antenna options, allowing for flexibility in deployment.
• Extended Frequency Range: Operates within the 4.9–6.4 GHz range, ideal for escaping noise and interference.
• Best-in-Class Noise Immunity: Designed to reduce localized noise with breakthrough front-to-back and front-to-side performance.
• Ultra Rugged Design: Encased in a die-cast aluminum enclosure with an IP67 rating, ensuring durability in harsh outdoor conditions.
• Low-Power Consumption: Efficient power usage, maximizing operational efficiency.
• High Throughput: Achieves speeds up to 700 Mbps in PTP mode and 500 Mbps in PTMP mode.

Specifications

• Max Throughput: 700 Mbps (PTP), 500 Mbps (PTMP)
• Wireless Protocols: Mimosa SRS (GPS Sync); WiFi Interop
• Modes: PTP Backhaul; PTMP Client
• Frequency Range: 4900–6400 MHz
• Max Output Power: 27 dBm
• Power Consumption: 12.9 W Max
• Dimensions: 175 mm (height) x 70 mm (width) x 61 mm (depth)
• Weight: 0.37 kg
• Operating Temperature: -40°C to +55°C
• Ingress Protection: IP67
