Mimosa A5X - 4.9-6.4GHz PTMP Access Point

The Mimosa A5X is a powerful and cost-effective connectorized access point designed for point-to-multipoint (PTMP) applications. Operating in the 4.9-6.4 GHz frequency range, it delivers fiber-like speeds of up to 700 Mbps, making it ideal for both short and long-range deployments. With its robust design and advanced features, the A5X ensures reliable connectivity and high performance in various environments.

Features

• Cost-Effective Solution: Offers high-speed connectivity at a fraction of the cost of fiber.
• Wide Frequency Range: Operates between 4.9 GHz to 6.4 GHz, allowing for access to low-noise spectrum.
• High-Speed Connectivity: Delivers fiber-like speeds of up to 700 Mbps (IP).
• Robust Design: IP67 rated, ensuring durability against harsh outdoor conditions.
• Short to Long-Range Applications: Suitable for pole and tower PTMP deployments.
• Easy Deployment: Connectorized design allows for quick and flexible installations.
• Compatible with Various Antennas: Works well with most 2x2 third-party antennas, including Mimosa's recommended N5-45x2.

Specifications

• Dimensions: 188.4 mm height x 75 mm width x 44 mm depth
• Weight: 0.7 kg
• Power Consumption: 9-12.9 W Max
• Frequency Range: 5150-5850 MHz (FCC/ETSI/CA), 4900-6400 MHz (ROW)
• IP Rating: IP67
