Milesight Smart Current Transformer - Energy MonitoRing

The Milesight Smart Current Transformer CT10x is an advanced energy monitoring solution designed for seamless integration into smart buildings. With its compact size and non-invasive installation, it ensures accurate energy usage analysis while minimizing downtime during setup.

Features

• LoRaWAN® Connectivity: Enables remote monitoring and data analysis through Milesight IoT Cloud and compatible gateways.
• High Input Current Capacity: Supports a maximum input current of 300A, making it suitable for a variety of applications.
• Induced Current Power Supply: Eliminates the need for external power sources, simplifying installation.
• Compact and Lightweight Design: The clamp construction allows for quick and safe mounting without de-energizing the facility.
• Real-Time Monitoring: Provides cumulative ampere-hours calculations every second for precise energy consumption tracking.
• Threshold Alerts: Configurable minimum and maximum current thresholds with instant alerts for proactive management.
• Temperature Monitoring: External wire temperature sensor option to trigger alerts when temperature thresholds are reached.

Specifications

• Maximum Input Current: 300A
• Sampling Frequency: 3.3 kHz
• Power Supply: Induced current power supply
• Ingress Protection: IP30
• Operating Temperature: -40°C to 55°C
• Storage Temperature: -25°C to 80°C
• Dimensions (Transceiver): 38 × 39.7 × 16 mm
• Dimensions (CT Clamp): 65.52 × 90 × 43 mm
• Weight (Transceiver): 13.05 g
• Weight (CT Clamp): 276.75 g
