MikroTik mANTBox ax 15s WiFi 6 Integrated Sector Antenna

The MikroTik mANTBox ax 15s is a powerful dual-band WiFi 6 integrated sector antenna designed to deliver exceptional outdoor wireless connectivity. With its advanced features and robust design, it is perfect for outdoor networks in locations such as parks, stadiums, and camps.

Features

• WiFi 6 Technology: Offers enhanced speed and efficiency with up to 40% higher speeds in the 5 GHz spectrum and up to 90% higher in the 2.4 GHz spectrum.
• Dual-Band Connectivity: Supports both 2.4 GHz and 5 GHz frequencies, providing flexibility in network deployment.
• Long Range: Capable of providing wireless connectivity over distances of up to 20 kilometers.
• Integrated Sector Antenna: Features built-in antennas with 12 dBi gain at 2.4 GHz and 15 dBi gain at 5 GHz for improved signal strength.
• Gigabit Ethernet Port: Includes one 10/100/1000 Ethernet port for high-speed wired connections.
• SFP Port: Equipped with a 2.5 Gbps SFP port for fast fiber uplinks.
• Robust Design: Built with a durable, weatherproof enclosure suitable for outdoor environments.
• Power over Ethernet (PoE): Supports PoE-in with included injector, simplifying installation.
• Advanced Management Features: Includes WPA3 security and seamless fast transition for improved user experience.

Specifications

• Product Code: L22UGS-5HaxD2HaxD-15S
• CPU: Dual-Core IPQ-5010, 800 MHz
• RAM: 256 MB
• Storage: 128 MB, NAND
• Operating System: RouterOS v7, License level 4
• Max Power Consumption: 21 W
• Operating Temperature: -40°C to +70°C
• Dimensions: 349 x 140 x 82 mm
• Weight: 1.4 kg
• USB Ports: 1 x USB 2.0
• Ethernet Ports: 1 x 10/100/1000
• SFP Ports: 1 (2.5G supported)
• Antenna Gain: 2.4 GHz - 12 dBi, 5 GHz - 15 dBi
