Mean Well 60W AC-DC High Reliability Power Supply

The Mean Well 60W AC-DC High Reliability Power Supply is a robust and efficient power solution designed for industrial applications. It features a compact design, high efficiency, and multiple protections to ensure reliable operation in demanding environments.

Features

• High Efficiency: Offers efficiency ratings up to 87%, reducing energy consumption.
• Wide Input Voltage Range: Accepts input voltage from 85 to 264VAC, making it versatile for various applications.
• Robust Protection Features: Includes overload, over-voltage, and short-circuit protection to ensure safety and reliability.
• Compact Size: Designed for DIN rail mounting, saving space in industrial settings.
• High Reliability: Built for long-term performance with an MTBF of over 2355.2K hours.

Specifications

• Model: MDR-60-48
• Rated Output Power: 60W
• Output Voltage: 48V
• Rated Current: 1.25A
• Input Voltage Range: 85 ~ 264VAC
• Frequency Range: 47 ~ 63Hz
• Efficiency: 87% (typical)
• Hold Up Time: 50ms at full load
• Operating Temperature: -20 ~ +70°C
• Dimensions: 40 x 90 x 100 mm
• Weight: 0.33 kg
• Protection Type: Constant current limiting, recovers automatically after fault condition is removed
