Mean Well - 25W DC-DC Converter - 24V Output

The Mean Well 25W DC-DC Converter is a reliable power supply solution designed to convert a wide range of input voltages into a stable 24V output. Ideal for various applications, this converter ensures efficient power management and robust performance in demanding environments.

Features

• Wide Input Voltage Range: Accepts input voltages from 36V to 72V DC, making it versatile for different applications.
• Stable Output: Provides a consistent output of +24V DC at a maximum current of 1.1A, ensuring reliable performance.
• Compact Design: The converter's compact dimensions of 97mm x 36mm x 99mm make it easy to integrate into various systems.
• High Efficiency: Achieves efficiency levels of up to 81%, minimizing energy loss and heat generation.
• Protection Features: Equipped with overload and over-voltage protection, ensuring safe operation under various conditions.

Specifications

• Model: SD-25C-24
• Input Voltage: 36 - 72V DC
• Output Voltage: 24V DC
• Output Current: 1.1A
• Rated Power: 25W
• Efficiency: Up to 81%
• Dimensions: 97mm (W) x 36mm (H) x 99mm (D)
• Weight: 0.38 kg
• Operating Temperature: -20°C to +60°C
• Humidity: 20% to 90% RH non-condensing
