IgniteNet Indoor Coax Bridge - Gigabit Ethernet

The IgniteNet Indoor Gigabit Ethernet to Coax Bridge is a powerful solution designed for service providers to deliver gigabit speeds over existing and new coax cabling infrastructure. It simplifies the process of providing bandwidth to buildings with outdoor coax and enhances connectivity within buildings using existing coax systems. With integrated Wi-Fi capabilities and cloud management, it streamlines installation and management for optimal performance.

Features

• High Performance: Delivers up to 2 Gbps PHY rate, supporting multiple G.hn baseband bandplans (25, 50, 100, 200 MHz).
• Integrated Wi-Fi: Features an integrated 2.4GHz radio for Wi-Fi connectivity and easy setup.
• Reverse Power Feed: Allows powering remote rooftop converters and backhaul over the same coax cable.
• Cloud Management: Utilizes ECcloud for seamless monitoring and management of up to 50 devices.
• Robust Security: Offers 128-bit AES CCMP encryption and strict authentication rules for secure data transmission.
• Scalable Connectivity: Connects up to 15 client converters to a single GLinq master device for extensive coverage.

Specifications

• Operating Voltage: 12 – 54 V
• Power Consumption: 6.5 W max
• Weight (Indoor): 220 g
• Dimensions (Indoor): 131 x 26 x 100 mm
• Wi-Fi Standards: 802.11b/g/n, 2x2 (2.4GHz)
• RF Performance (TX): 2.4GHz: 25 dBm @ 6Mbps, 18 dBm @ 300Mbps
• RF Performance (RX): 2.4GHz: -90 dBm @ 6Mbps, -72 dBm @ 300Mbps
• Antenna Gain (Indoor): 3 dBi omni-directional
• Security Protocols: WPA, WPA2-PSK, WPA2-AES
