DSPPA WH-7F SP IW - Square Plastic In-Wall Mounting Box for WH-706/712

The DSPPA WH-7F SP IW is a high-quality square plastic in-wall mounting box designed for seamless integration with WH-706 and WH-712 volume controllers. Its streamlined design and robust construction ensure compatibility with various decorative styles while providing an ergonomic and user-friendly experience.

Features

• Streamlined Design: The lightweight cover and rounded appearance make it suitable for any decorative style.
• Ergonomic Knob: The large knob design allows for easy rotation and is labor-saving.
• High-Quality Material: Made from environmentally friendly ABS plastic, it is tasteless, odorless, and harmless to the human body. It also offers impact resistance and is not easily deformed.
• Powerful Functionality: Supports 6 gear control and emergency broadcast signal override functionality.
• Simple Installation: Designed with international general size specifications for easy installation and disassembly.

Specifications

• Model: WH-7F
• RMS: 6W, 15W, 30W, 60W
• Input Voltage: 70V/100V
• Attenuation Range: 6×3dB
• Frequency Response: 50Hz-20kHz
• Total Harmonic Distortion (THD): <0.5%
• Package Size: 155×75×70mm
• Product Size: 114×70×55mm
• Product Weight: 0.225kg, 0.235kg, 0.310kg, 0.425kg
• Color: White
• Application Cable: Two-wire, Four-wire, Six-wire
