DSPPA MP-1000PIII: 350W Mixer Amp, 3 Mic &

The DSPPA MP-1000PIII is a powerful 350W line mixer amplifier designed for commercial audio applications. With 3 microphone inputs and 2 auxiliary inputs, it is ideal for environments such as supermarkets, classrooms, and conference rooms. This amplifier features individual volume controls, tone adjustments, and a comprehensive protection system for reliable operation.

Features

• Rated Power: 350W output power suitable for various applications.
• Microphone Inputs: 3 microphone inputs with Mic 1 having priority and muting function.
• Auxiliary Inputs: 2 auxiliary inputs for additional audio sources.
• Tone Control: Adjustable bass and treble controls for sound customization.
• Protection Features: Includes short circuit protection, thermal protection, and overload protection.
• LED Level Meter: Provides visual monitoring of sound levels for easy adjustments.

Specifications

• Rated Output Power: 350W
• Speaker Output: 70V, 100V & 4-16 Ω
• Input Sensitivity: Mic 1 ≤3.3mV (unbalanced), Line ≤300mV (unbalanced)
• Frequency Response: 80Hz - 16KHz (±3dB)
• Distortion: ≤1% (1KHz, normal operating status)
• S/N Ratio: ≥74dB
• Tone Control: Bass ±10dB (100Hz), Treble ±10dB (10kHz)
• Power Requirements: AC 220V/50Hz
• Rated Power Consumption: 120W
• Outer Packing Size: 520mm x 430mm x 195mm
• Unit Size: 483mm x 338mm x 88mm
• Gross Weight: 10.3kg
• Net Weight: 8.5kg
