Chamsys QuickQ 20: Compact Console for Dimmers, LEDs, Moving Lights

The Chamsys QuickQ 20 is an intuitive and compact lighting control console designed for both novice and experienced users. With a user-friendly interface modeled after smartphones, it simplifies the control of dimmers, LED color mixing, and moving light fixtures. Its large 9.7-inch touchscreen allows for easy setup, programming, and playback, making it an ideal choice for various applications including concerts, nightclubs, theaters, and houses of worship.

Features

• Large Touchscreen: A 9.7-inch multi-touch display that supports gestures for zooming and scrolling.
• User-Friendly Interface: Smartphone-like interface with icons and gesture support for easy navigation.
• Inbuilt Wi-Fi: Enables remote connection to the free QuickQ app on iOS, Android, and Windows devices.
• Automated Patching: Automatically detects and patches RDM compliant fixtures.
• Extensive Fixture Library: Access to over 45,000 personalities for quick setup.
• Offline Programming: Free software available for Mac and Windows to program shows offline.
• Playback System: Features 10 multi-cue playback faders and a dedicated Grand Master fader for overall level control.
• Dedicated Color Control: Includes Hue and Saturation encoders for precise color mixing.
• Support for DMX Output: Capable of outputting DMX over network via ArtNet/sACN/Pathport.
• Future-Proof: QuickQ shows are compatible with MagicQ systems for easy upgrades.

Specifications

• Max Number of DMX Channels: 1024
• Max Number of Fixtures Supported: 1024
• Max Number of Cue Stacks: 10
• Max Number of Chases: 10
• Universes Supported: 2
• Direct DMX Outputs: 2 (5-Pin XLR)
• Master Playback Faders: 10
• Multi-Function Fixture Faders: 20
• Attribute Encoders: 4
• Inbuilt Wi-Fi: Yes
• Network Port: 1
• USB Ports: 2
• Audio Input: 1
• Audio Output: 1 (MIDI Ports and Audio Out enabled via future software update)
• Dimensions (W x D x H): 565mm x 350mm x 106mm
• Weight: 5.2kg
