Chamsys MagicQ Compact Connect: USB Control Surface for PC/Mac.

The Chamsys MagicQ Compact Connect is a versatile USB control surface designed for seamless integration with PC and Mac systems, enabling efficient control of lighting and video equipment using MagicQ software. Its compact design meets hand luggage regulations, making it ideal for touring professionals.

Features

• Compact Design: Lightweight and portable, compliant with hand luggage regulations of major airlines.
• 10 Playback Faders: Control up to 500 pages of cues with illuminated playbacks for easy visibility.
• 64 Universe Output: Built-in network interface supports up to 64 universes via ArtNet and sACN without additional licenses.
• Direct DMX Outputs: Two XLR 5-pin DMX outputs that are RDM capable for enhanced compatibility.
• Multiple USB Ports: Includes one USB-C input and four USB-A outputs for connecting additional devices.
• Attribute Encoders: Eight rotary encoders for direct access to fixture parameters.
• Integrated USB Hub: Provides additional connectivity options for peripherals.
• Audio Input: 1-channel audio input for integrating sound control.
• Scene Input: 10Scene/Remote Input port for enhanced control options.
• Working Light Socket: Built-in socket for convenient lighting during operation.

Specifications

• Dimensions: 522mm (W) x 230mm (D) x 65mm (H)
• Weight: 3.65 kg
• Power Input: Neutrik powerCON TRUE1, 110 to 240 VAC
• Maximum DMX Channels: 32,768
• Maximum Fixtures Supported: 32,768
• Maximum Number of Cues: 5,000
• Maximum Number of Cue Stacks: 2,000
• Maximum Number of Groups: 5,000
• Maximum Number of Palettes: 4,096
• Supported Operating Systems: Windows (8.1 or higher), macOS (10.13 or higher), Linux
