AVLINK 25-Way Mini D-SUB Male Connector for PCB and Cable Use

The AVLINK D-SUB Mini Male Connector features a 25-way configuration with crimp termination, ideal for connecting PCBs and cables. Designed for reliability, this connector ensures a secure connection with a fixing flange and feed-through hole, making it perfect for various electronic applications.

Features

• 25-Way Configuration: Provides multiple connection points for versatile applications.
• Crimp Termination: Ensures a solid and reliable connection to cables and PCBs.
• Male Gender: Designed for use with female connectors, enhancing compatibility in setups.
• Fixing Flange: Includes a flange with a feed-through hole for secure mounting.
• High Insulation Resistance: Greater than 1 GΩ for improved safety and performance.

Specifications

• Connector Type: D-Sub Mini Male
• Number of Contacts: 25
• Termination Method: Crimp
• Conductor Cross-Section: 0.09 to 0.82 mm² (AWG 28 to AWG 18)
• Wire Outer Diameter: Up to 2.4 mm
• Temperature Range: -55 °C to +125 °C
• Insulation Resistance: > 1 GΩ
• Test Voltage: 1 kV
• Material: Thermoplastic resin, glass-fibre filled (PBTP) for the insert; plated steel for the shell.
• RoHS Compliant: Yes
• Country of Origin: China
