Audio-Technica AT-VM95SH Cartridge with Shibata Stylus

The Audio-Technica AT-VM95SH is a high-performance dual moving magnet cartridge featuring a Shibata stylus, designed for audiophiles seeking exceptional sound quality. Its innovative design ensures precise tracking and minimal distortion, making it perfect for vinyl enthusiasts who demand the best in audio fidelity.

Features

• Shibata Stylus: The 2.7 x 0.26 mil Shibata stylus design provides superior high-frequency response and minimal groove stress for better sound quality.
• Dual Moving Magnet Design: Offers enhanced channel separation and tonal accuracy, closely mimicking the cutter head used in vinyl mastering.
• Low-Resonance Housing: The durable polymer construction minimizes unwanted resonance for clearer sound reproduction.
• Easy Installation: Threaded inserts allow for easy mounting to the headshell using just two screws, eliminating the need for nuts.
• Interchangeable Stylus: Compatible with any AT-VMN95 replacement stylus, providing flexibility for future upgrades.

Specifications

• Frequency Response: 20-25,000 Hz
• Channel Separation: 23 dB at 1 kHz
• Vertical Tracking Angle: 23°
• Vertical Tracking Force: 1.8-2.2 g (2.0 g standard)
• Stylus Construction: Nude square shank
• Recommended Load Impedance: 47,000 ohms
• Coil Impedance: 3.3 k ohms (1 kHz)
• DC Resistance: 485 ohms
• Coil Inductance: 550 mH (1 kHz)
• Output Voltage: 3.5 mV (1 kHz, 5 cm/sec.)
• Output Channel Balance: 1.5 dB (1 kHz)
• Static Compliance: 20 x 10^-6 cm/dyne
• Dynamic Compliance: 10 x 10^-6 cm/dyne (100 Hz)
• Cartridge Weight: 6.1 g
• Dimensions: 17.2 mm (H) x 18.9 mm (W) x 28.3 mm (D)
• Recommended Load Capacitance: 100 to 200 pF
