Audac Dual-channel Class-D amplifier 2 x 250W

The Audac EPA252 is a high-performance dual-channel Class-D amplifier, perfect for both fixed and mobile audio installations. Delivering 2 x 250W at 4 ohms, it combines energy efficiency with outstanding sound quality. Its compact design and lightweight construction make it ideal for various applications, including bars, restaurants, clubs, and corporate events. With advanced protection circuitry and passive cooling, the EPA252 ensures reliable operation with minimal maintenance.

Features

• Energy Efficient: Automatically switches to standby mode when no audio signals are detected, consuming less than 1W in standby.
• Compact Design: Single rack space size, making it perfect for mobile and fixed installations.
• Class-D Technology: Provides high efficiency and excellent sound quality with low heat dissipation.
• Advanced Protection: Features protection against DC malfunctioning, short circuits, overheating, and overload.
• Minimal Maintenance: Passive cooling design reduces the need for regular maintenance.

Specifications

• RMS Power Handling (4 Ω Stereo): 2 x 250 W
• RMS Power Handling (8 Ω Stereo): 2 x 130 W
• RMS Power Handling (8 Ω Bridge): 500 W
• Frequency Response: 20 Hz - 20 kHz (± 3 dB)
• Signal-to-Noise Ratio: > 90 dB
• Total Harmonic Distortion + Noise (@ 1 kHz): < 0.1%
• Crosstalk (@ 1 kHz): > 70 dB
• Input Sensitivity: 0 dB (1V RMS)
• Input Impedance: 12 kΩ balanced
• Cooling: Convection cooled
• Operating Temperature: 0° ~ 40° @ 95% Humidity
• Power Supply: Switching mode (100 ~ 240 V AC / 50 ~ 60 Hz)
• Dimensions: 482 x 44 x 330 mm (W x H x D)
• Weight: 4.4 kg
