Atlona (Rx Only) HDBaseT Scaler with HDMI and Analog Audio Outputs

The Atlona AT-HDVS-150-RX is a high-performance HDBaseT receiver and scaler designed for seamless video signal transmission and scaling up to 1080p. Ideal for use in classrooms, huddle rooms, and meeting spaces, this compact device simplifies AV integration with features like automatic display control, audio de-embedding, and advanced scaling capabilities.

Features

• HDBaseT Receiver and Scaler: Supports video signals up to 1080p and embedded audio over distances up to 230 feet (70 meters).
• Automatic Display Control: Automatically powers on and off displays based on device connection, enhancing user experience.
• Power over Ethernet (PoE): Remotely powers the HDVS-150-TX transmitter, simplifying installation and reducing cable clutter.
• Advanced Scaling Capabilities: Features image adjustment and automatic signal matching to the display's native resolution for optimal viewing.
• Audio De-embedding: Extracts audio signals for use in external audio systems, providing flexibility in audio management.
• RS-232 Control: Allows third-party control of the scaler, switcher, and display, making integration with existing systems straightforward.
• Compact Design: Can be easily surface-mounted for installation behind displays or above projectors.

Specifications

• Input Resolution: Up to 1080p@60Hz, 1920x1200
• Output Resolution: Up to 1080p@60Hz, 1920x1200
• Distance: Up to 230 feet (70 meters) over CAT6a/7 cabling
• Audio Format: PCM 2Ch (De-embedded)
• Bandwidth: 6.75 Gbps
• Power Consumption: 15W
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Weight: 0.31 kg (0.67 lbs)
• Dimensions: 30 x 122 x 125 mm (H x W x D)
• Certifications: CE, FCC
