Atlona HDVS-150-TX-PSK: 3-Input HDBaseT Trans

The Atlona HDVS-150-TX-PSK is a versatile three-input HDBaseT transmitter designed for seamless integration with HDBaseT-equipped projectors. Featuring two HDMI inputs and one VGA input with audio, this compact switcher allows for long-distance AV signal transmission up to 230 feet (70 meters) at 1080p and 130 feet (40 meters) for 4K/UHD video at 60 Hz. With automatic input selection, display control, and local powering capabilities, it simplifies AV system installations in classrooms, huddle rooms, and corporate environments.

Features

• Three-Input Switching: Supports two HDMI and one VGA input for versatile connectivity.
• Automatic Input Selection: Detects active sources and switches inputs without user intervention.
• Long-Distance Transmission: Extends AV signals up to 230 feet (70 meters) at 1080p and 130 feet (40 meters) for 4K/UHD.
• Power over Ethernet (PoE): Can be powered by the receiver, eliminating the need for local AC power.
• Automatic Display Control: Triggers display power on/off based on connected devices.
• Compact Design: Ideal for under-table or wall-mounted installations.

Specifications

• Inputs: 2 HDMI, 1 VGA
• HDBaseT Transmission: Up to 230 feet (70 meters) at 1080p
• 4K/UHD Capability: Yes, up to 130 feet (40 meters) at 60 Hz with 4:2:0 chroma subsampling
• Audio Support: Embedded audio with VGA input
• Control: RS-232 for display control
• Firmware: Field-updatable
• Dimensions (H x W x D): 1.5 x 5 x 4.02 inches (38 x 127 x 102 mm)
• Weight: 2.34 kg (5.16 lbs)
