Amphenol K Series 3.5mm Mono Plug - Diecast Shell, Satin Finish

The Amphenol K Series 3.5mm Mono Phone Plug features a robust diecast zinc alloy shell with a sleek satin finish, designed for professional audio and lighting applications. This high-quality connector ensures reliable performance and durability, making it an ideal choice for musicians, sound engineers, and audio technicians.

Features

• Professional Grade: Designed for applications that require a robust interconnect.
• Diecast Zinc Alloy Shell: Provides excellent durability and a stylish satin finish.
• Solder Contacts: Ensures a secure and reliable connection.
• Flexible Cable Grommet: Accommodates various cable sizes for enhanced versatility.
• Metal Cable Clamp: Offers additional strain relief for improved durability.

Specifications

• Positions: 2
• Finish: Satin
• IP Rating: IP40
• Current Carrying Capacity: >0.5mA (Depending on mating connector and cable)
• Termination: Solder
• Max Wire Gauge: 16AWG - 1.5mm²
• Flammability Rating: UL94V-0 or UL94-HB
• Environmental Compliance: Complies with EU RoHS 2 Directive 2011/65/EU
• Typical Contact Resistance: < 20mΩ (Depends on mating connector)
• Insulation Resistance: >200MΩ / >100MΩ after Damp Heat Test
• Operating Temperature: -20°C to +65°C (-4°F to 149°F)
• Insertion and Withdrawal Force: < 20N / > 30N (depends on mating connector)
• Cable OD Range: 3mm to 5mm (0.118" to 0.196")
• Mating Cycles: 1000
