Amphenol AX3F Female XLR 3 Inline Connector with Nickel Finish

The Amphenol AX3F Female XLR 3 Inline Connector is a premium choice for professional audio applications, combining a contemporary design with exceptional sound performance. Engineered to fit seamlessly into modern audio setups, this connector features a chuck style cable clamp for secure attachment and easy handling. The nickel finish not only enhances durability but also provides a sleek look, making it ideal for both studio and live sound environments.

Features

• Contemporary Design: Modern aesthetic that complements contemporary audio architecture.
• Chuck Style Cable Clamp: Accommodates cable diameters from 3mm to 8mm (0.118” – 0.314”) for versatile use.
• Ergonomic Sleeve: Designed for improved grip, ensuring easy handling even in demanding situations.
• Concealed Latching Point: Provides improved aesthetics and strength while enhancing sealing.
• Precision Machined Contacts: Ensures optimal contact resistance for superior audio performance.
• Zinc Diecast Shell: Offers robustness and wear resistance, ensuring longevity in use.

Specifications

• Connector Type: Female XLR 3
• Contact Plating: Nickel
• Current Carrying Capacity: 15A
• Max Wire Gauge: 14AWG
• Operating Temperature: -25°C to +75°C (-13°F to +167°F)
• Mating Cycles: 1000
• Insulation Resistance: < 1GΩ
• Typical Contact Resistance: < 3mΩ
