Adastra CC6V 2-Way Ceiling Speaker, 6.25" Dual Cone,

The Adastra CC6V 2-Way Ceiling Speaker is designed for efficient sound distribution in both home and commercial environments. Featuring a 6.5-inch dual cone design, this speaker delivers exceptional audio quality with a frequency response of 70Hz to 20kHz. The white polymer frame with a metal grille ensures a sleek look while providing durability. Its quick-fit installation with 'dog-ear' mounts makes it easy to install in ceiling tiles ranging from 1-20mm thick. The rotary selector switch allows for convenient adjustment between 100V line tappings or 8 Ohms.

Features

• 2-Way System: Combines a 165mm (6.5") woofer and a 38mm (1.5") tweeter for balanced sound.
• Rotary Selector Switch: Easily switch between 100V line tappings or 8 Ohm settings.
• Quick Fit Installation: Fitted with 'dog-ear' mounts for easy fixing to ceiling tiles.
• Spring Loaded Terminals: Simplifies the connection process for quick setup.
• Wide Dispersion Angle: 160° dispersion angle for effective sound coverage.

Specifications

• Power RMS (100V line): 20W
• Power RMS (8 Ohms): 50W
• Power Max (8 Ohms): 100W
• Frequency Response: 70Hz - 20kHz
• SPL @ 1W/1m: 87dB (±2dB)
• Dimensions: 100 x 227mm
• Mounting Depth: 90mm
• Cutout Diameter: 193mmØ
• Weight: 1.25kg
• Tappings: 2.5, 5, 10, 15, 20W & 8 Ohms
