Ubiquiti UniFi Flex 2.5G 8 Port 2.5G with 10G Combo Uplink | USW-Flex-2.5G-8

The Ubiquiti UniFi Flex 2.5G 8-Port Switch (USW-Flex-2.5G-8) is a compact, managed network switch designed to enhance network performance with its eight 2.5 GbE RJ45 ports and a 10 GbE RJ45/SFP+ combination uplink port. This switch is ideal for environments requiring high-speed connectivity, such as offices, data centers, and home networks with demanding bandwidth needs. Its versatile mounting options and silent, fanless design make it suitable for various installations, including desktop, wall, DIN rail, and magnetic mounting.

Features

• Eight 2.5 GbE RJ45 ports for high-speed device connections.
• One 10 GbE RJ45/SFP+ combination uplink port for flexible connectivity options.
• Total non-blocking throughput of 30 Gbps and a switching capacity of 60 Gbps.
• Forwarding rate of 45 Mpps.
• Support for 256 VLANs and a MAC address table size of 4,000 entries.
• Layer 2 features including STP, RSTP, egress rate limiting, flow control, storm control, multicast and broadcast rate limiting, port isolation, port mirroring, jumbo frames, and loop protection.
• Multiple mounting options: desktop, wall, DIN rail, and magnetic.
• Fanless design for silent operation.
• Power options include USB Type-C (5V DC, 3A) and PoE+ input.
• Managed via UniFi Network application (version 9.0.114 and later).

Specifications

• Dimensions: 212.9 x 76 x 33.5 mm (8.4 x 3 x 1.3 inches)
• Weight: 395 g (0.87 lb)
• Enclosure Material: Polycarbonate
• Switching Capacity: 60 Gbps
• Total Non-Blocking Throughput: 30 Gbps
• Forwarding Rate: 45 Mpps
• Supported VLANs: 256
• MAC Address Table Size: 4,000
• Layer 2 Features: STP, RSTP, egress rate limiting, flow control, storm control, multicast and broadcast rate limiting, port isolation, port mirroring, jumbo frames, loop protection
• Power Consumption: 14W with PoE input; 14W with AC adapter input
• Power Method: USB Type-C (5V DC, 3A) or PoE+
• Supported Voltage Range: 4.8–5.2V DC (USB); 44–57V (PoE)
• Operating Temperature: -20 to 45°C (-4 to 113°F)
• Operating Humidity: 10 to 90% non-condensing
• Certifications: CE, FCC, IC, Anatel
